SUB218 A

PRODUCT DESCRIPTION

Classic subwoofer
The sound from the SUB218 is suitable for large indoor spaces: not only at 80 Hz, but even at an altitude of more than one octave, it always maintains high efficiency. Its low frequency is not only strong, but also high in sound quality. This outstanding performance is due to the use of two high-performance 18" long-stroke woofers. The relatively light moving mass of the paper tray combined with the push-pull technology gives it a very fast response.

APPLICITION

Large PA system
Open-air plaza
chapel
Disco & Nightclub

FEATURES

  • Two-way active coaxial system.
  • High-efficiency and high-power PWM amplifier circuit, no fan cooling required.
  • FIRTEC™ unique DSP processing technology.
  • Input can receive digital (AES standard) signal and analog signal.
  • Standard network protocol control system for real-time detection of signal and temperature status.



SPECIFICATIONS

Frequency Response 36-200 Hz +-3dB
Power 2000 Wrms (1000W + 1000W)
SPL 136dBpeak
Dispersion (H/V)

Spherical Pointing

Crossover point

70-120 Hz

Driver Unit 2 x 18"- Conical driver
Power amplifier

2 x PWM, SMPS, built - in

Connectors

Built - in

Dimensions(H x W x D)
575 x 1010 x 800 mm
Net Weight
72kg
Features
Integrated Line Array Plug - in
