OPERATION T212B

Dual 12" Subwoofer

FEATURES

  • Powerful 1000W subwoofer, featuring a dual 12" driver by B&C.
  • Frequency extends down to 35 Hz, whilst retaining enough energy to be useful when required.
  • Precision-made 15-ply 24 mm and 11-ply 18 mm Baltic birch plywood cabinet, with a durable paint finish for touring and rental use.
  • Reinforced V-Slot grille reduces internal vibration noise.
  • The LF driver features a humidity resistant paper cone.
  • The integrated rigging system has a 7:1 safety coefficient.
  • Designed for touring, outdoor concerts, stadiums, fixed installation and for all demanding sound reinforcement applications.
  • Designed to be flown in ATEC OP T10 Line Array Systems.



SPECIFICATIONS

Frequency Response 42Hz - 200Hz (+- 3dB) / 35Hz - 200Hz (- 10dB)
Sensitivity (1W / 1m) 99dB
SPL (1m)
129dB (Continuous) / 135dB (Peak)
Power Rating (AES) 1000W
Nominal Impedance
8 ohm
Driver 2 x 12" Neodymium / 75 mm Voice Coil
Enclosure
Phase Inverted
Fittings OP T10 FK
Connectors
NEUTRIK NL4MP  LF: 1+1-
Dimensions (W x D x H) 850 x 350 x 515 mm
Net Weight
36 kg
